Cables:
Main Power Connector (20 + 4 Pin): 500mm x 1
ATX 12V (4 + 4 Pin): 550mm x 1
SATA (4 Pin): 500mm+100mm+100mm x 6
PCI-E (6+2 Pin): 500mm+100mm x 2
Peripheral (4 Pin): 500mm+100mm+100mm x 3
FDD (4 Pin): 100mm x 1
ESPESIFICACIONES
P/N: PS-SPR-0600NHFAWx-1
Short P/N: SPR-0600NHFAW
Model: SPR-600AH2NK-1
Type: Intel ATX 12V 2.3
Max. Output Capacity: 600W
Color: Black
Dimension (H x W x D): 86mm x 150mm x 140mm
PFC (Power Factor Correction: Active PFC
Power Good Signal: 100-500 msec
Hold Up Time: 16msec (minimum) within 60% load
Input current: 10A max
Input Frequency Range: 50 Hz - 60 Hz
Input Voltage: 100Vac - 240Vac
Operating Temperature: 5¿ to +40¿
Operating Humidity: 20% to 85%-non-condensing
Storage Temperature: -40 ¿ to +55 ¿
Storage Humidity: 10% to 95%- non-condensing
Cooling System: 120mm Fan: 1800 R.P.M. ± 10%
Efficiency: 82-86% efficiency @ 20-100% load
MTBF: 100-000 hrs minimum
Safety Approval: CE/CB/TUV/ UL/ FCC/ EAC
Protection: OVP- OPP- SCP
