ATX 12V V2.3 enables most reliable and robust power delivery.
- Stable 500W continuous output (peak power 600W) @ 40 ? operating environment.
- Robust and dedicated single +12V output provides superior performance under all types of system loading.
- 80 PLUSR Bronze Certified: with 82-88% efficiency @ 20-100% load under real world load conditions.
- Double-forward switching circuitry offers low power loss and high reliability.
- Universal AC input 100V~240V automatically scans and detects the correct voltage.
- High quality 105 ? Japanese main capacitor provide uncompromised performance and reliability.
- 99% Active Power Factor Correction provides clean and reliable power to your system.
- Ultra-silent operation with intelligent 12cm cooling fan speed control.
- Intel & AMD CPU compliant.
- Nvidia & ATI/AMD graphic card compatible.
- Dimension: 150mm(W)x86mm(H)x140mm(L).
- High reliability: MTBF>100-000 hours.
- Built in industrial-grade protections: Over Current- Over Voltage- Under Voltage- Over Power and Short-Circuit protections.
- Safety / EMI : UL/ CUL- TUV- CE- FCC- CB- GOST and BSMI certified.
High Quality 105°C Japanese Electrolytic Capacitor
105°C Japanese main capacitor provides uncompromised performance and reliability.
Industrial Grade Protection
Built in industrial-grade protections: Over Current- Over Voltage- Under Voltage- Over Power and Short-Circuit protections
Ultra Quiet 12cm Fan
New TR2 series adopt 12cm cooling fan with intelligent RPM control guarantees cool performance and silent operation.
High Efficiency Circuit Design
Maximum efficiency up to 88% under wide load range.
80 Plus Bronze Certified New TR2 Series saves energy through its high energy efficiency of up to 88% and is 80 PLUSR Bronze certified
New TR2 Series fulfils the EU guideline for ErP (Energy-related Products) that are scheduled to apply starting in 2010.
Supports Energy Star 5.0* energy standard:
New TR2 Series is suitable for use in Energy Star-compatible computers.
Supports Intel Deep Power Down C6 Status:
New TR2 Series helps your PC system operate more power efficiently.
Corresponds to the EU directives on WEEE and RoHS:
Thermaltake considers its full impact on the environment during manufacturing and maintains green facilities to ensure TR2 meets WEEE & RoHS requirements.
AC INPUT Input Voltage: 100V-240V~
Input Current: 7A - 3.5A
DC OUTPUT +5V +3.3V +12V -12V +5Vsb
Max Output Current 24A 24A 36A 0.5A 2.5A
Max Output Power 123W 432W 6.0W 12.5W
Continuous Power 500W
Voltage Source Over Current Protection Over Voltage Protection Under Voltage Protection
Protection Point (Max.) Protection Point
+3.3V 60A 3.76V~4.8V 2.0V~2.4V
+5V 48A 5.6V~7.0V 3.3V~3.7V
+12V 60A 13.0V~16.5V 8.5V~9.5V
Short Circuit Protection: Activated when any DC rails short circuited.
Over Power Protection: Protection at 110%~130% full load.
Model Connector Type Connectors & Cable length
500W 24pin 1 x 20+4pin Main connector(550mm)
ATX 12V 4+4pin 1 x ATX 12V 4+4pin Connector (550mm)
PCI-E 6+2pin & 6pin 1 x 6+2pin & 1 x 6pin PCI-E connector (500mm + 150mm)
Molex & FDD 2 x Peripheral & 1 x FDD connectors (500mm + 150mm + 150mm )
3 x Peripheral connectors (500mm + 150mm + 150mm)
SATA 3 x S-ATA connectors (500mm + 150mm + 150mm)
2 x S-ATA connectors (500mm + 150mm)
